The slitting machine should improve the output and ensure the product quality at the same time

28. November, 2023delish0

The slitting machine should improve the output and ensure the product quality at the same time

In order to stabilize the quality of the slitting machine product and ensure the pass rate of the product, it is stipulated as follows:

1. Incoming inspection:

According to the quality of the incoming materials, wall thickness, the number of broken ends, to arrange the plan reasonably, the main operator should consider to ensure that the volume diameter and meters required by the customer are as far as possible to digest the broken end and reduce the joint rate. If the material with too many incoming broken ends and too many airways does not meet the requirements of foreign trade orders, priority should be given to the small shaft plan with some indefinite length. (Foreign trade orders generally require no joints or only one street is allowed, and the joint rate is within 20%)).

2. Thickness of the base:

The reasons for the thickness of the base are: (1) The core is unqualified: the wall thickness of the core is different, the surface quality is poor and uneven, and the qualified core should be replaced. (2) Poor incoming plate type: the incoming plate type is tight and loose on the loose side of the plate type when coiling, and the bar will be wrinkled, flicking, and the three plate rollers at the entrance should be adjusted to adjust the plate type, and the tension and pressure should be adjusted appropriately. (3) Improper setting of process parameters: there are errors in setting parameters: such as incoming width, thickness, dynamic compensation, tension gradient, pressure, tension, etc., further adjustment should be made according to the situation. (4) Machine problems: large runout of the winding shaft, large or small winding measurement, asynchronous rubber roller, electrical failure, etc., find an electric fitter to deal with it in time.

3. Slashes, soft bars:

The uneven lines on the surface of the aluminum coil are called slashes and soft bars, which often occur in the slitting process. (1) Excessive coiling tension will also cause soft bars, and the coiling tension should be appropriate and not too large during operation. (2) Improper adjustment of the pressure at both ends of the flattening roller and the support roller will also cause soft bars and slashes, and the pressure should not be greatly adjusted in the normal operation of the machine. (3) The unstable operation of the equipment, such as: the machine speed is too fast, the winding shaft runs, the rubber roller is out of sync, etc., which will cause the soft bar and slash to find an electric fitter in time to deal with it.

4. Welding:

(50) Wrinkle at the welding place after welding operation: if the belt is broken during the slitting process, it needs to be welded, and the small rolls of each shaft should be evenly picked. After the incoming material is broken and stopped, it is necessary to remove the number of meters generated after parking (because the tension may be too large during the parking process, resulting in the coil layer). Run as much as possible 100-3 meters after running at low speed with the belt, so as to avoid the string layer caused by the welding bar caused by the plate type not being straightened, the aluminum foil on the welding roller should be supplemented by flattening, and the upper and lower layers of anhydrous ethanol should be wiped to fix the aluminum foil, and the head should be aligned. After welding, the running tension should be appropriate, and too large or too small tension will also cause wrinkled strings (<>), and the welding is not firm: the tearing edge should be smooth, and there should be no burrs, forks, residual edges, etc. The aluminum foil overlap should not exceed <>mm, and there should be no bulging, bubbles, and wrinkles at the lap to prevent defects (damage, false welding, etc.) on the weld. (<>) Alcohol spots: When welding, in order to prevent aluminum from sticking to ensure the quality of welding, the disc must be moistened with alcohol or the aluminum foil should be wetted, and the amount of alcohol should not be too much, so as to attach to the aluminum coil and cause annealed macula.

5. Unloading into the frame:

In the process of unloading into the frame, the end face must be protected by a foam pad, and the material on the ground must be protected by a foam pad, and the material placed on the ground must be cushioned with felt or foam, and the surface is not allowed to produce obvious pitting, in addition, it is not allowed to put the material on the aisle.
