Why should the paper slitting machine install a magnetic particle brake

24. February, 2024|delish|0Views

Why should the paper slitting machine install a magnetic particle brake

The main function of the paper slitting machine is the slitting effect of the paper, we can see that its use plays a very important role in the slitting of the paper, but in the operation of the paper slitting machine, we need to use the magnetic powder brake to brake it, so let's talk about why the magnetic particle brake should be installed on the paper slitting machine?

Magnetic powder brake is the common name of magnetic powder brake, and the torque transmission is mainly based on magnetic powder, and magnetic powder is a consumable, so it needs to be replaced over time. The service life of the magnetic particle is related to the use environment, load situation, frequency of use, heat dissipation problems and the quality of the magnetic particle, and the more serious these problems, the faster the consumption of the magnetic particle. According to the shaft type, it is classified as: single-shaft magnetic powder brake and hollow shaft magnetic powder brake.

Magnetic powder brake tension control ^, simple, can prevent the paper slitting machine unwinding group material from moving, paper slitting machine magnetic powder brake using DC24V DC voltage, heat dissipation optional natural cooling (air cooling) or device fan for forced heat dissipation, please keep the paper slitting machine magnetic powder brake on the horizontal axis and the surrounding environment can not be too humid during installation.

The magnetic powder brake device is connected with the inflatable shaft with the transmission part on the paper slitting machine, and the unwinding speed is controlled by controlling the torque of the magnetic particle brake, and the degree of the magnetic powder brake is rewinded. According to the size of the whole roll of the unwinding group of the paper slitting machine, the magnetic particle brake is selected, and the common specifications of the magnetic particle brake of the paper slitting machine are 12Nm, 25Nm, 50NM, 100Nm, 200Nm, and 400Nm. The magnetic powder brake of the paper slitting machine is mainly to provide a balanced and stable torque, which can be adjusted with the tension controller, so that the unwinding work of the paper slitting machine and the efficiency and quality of the whole action can be improved.
